Proline® R-910

The Best Choice for User Efficiency and Flexibility

One step ahead

Proline® R-910 is a compact and fully-automated bench top analyzer for maximum efficiency. During its development, special attention was paid to easy handling and optimized work flow thus leading to the ideal clinical chemistry system for many laboratories.

Versatile and flexible

High on-board capacity of 30 different methods in mono- or twin-containers and 30 sample positions offers the necessary flexibility for everyday use. The integrated STAT port allows easy loading of emergency samples at any time. The wide range of high-quality clinical chemistry and immunoturbidimetric tests manufactured by Proline rounds off the Proline® R-910 system.

Easy to use

Ready-to-use reagents, adapter free one-grip loading of reagent containers, integrated bar code reader for sample and reagent as well as the intuitive software alleviates daily workload significantly.

Competitive and unique

Minimized service and maintenance costs, low reagent consumption, and high on board-stability of Proline system reagents in combination with the highest result safety add up for a highly competitive system. Further features like LIS-connectivity, clot detection, and crash sensor make Proline® R-910 unique in its class.

The new generation of automated testing

The new software version 4.8.0.8 is available for Proline® R-910 devices. We highly recommend upgrading all installed Proline® R-910 analyzers because it eases the daily laboratory routine. This new software leads to updated reliability and offers new and improved functionality as:

  • Improvement of 2 µl sample pipetting precision.
  • Modified cuvette acceptance criteria
  • Extended carry over evasion
  • Protecting your Proline reagent business by closing of channels
  • General handling improvements and bug fixes
System type Bench top clinical chemistry analyzer
Throughput up to 150 tests/hour
Combined reagent/sample tray 30 reagent positions plus 30 sample positionsl easily removable tray for storage in refrigerator
Sample types Serum, plasma, whole blood, CSF, urine
Sample volume 2-30 μL
Reagent pipetting volume Reagent 1: 120 – 250 μL. Reagent 2: 10 – 50 μL
STAT-analytics 2 sample positions for loading of emergency samples at any time
Ion measurement Enzymatic tests for Cl, K, Na, Li
Bar code identification Automatic bar code scan for reagents and samples
Measuring principle Colorimetry (Rate/End Point); Turbidimetric Immunoassay
Calibration Linear, non-linear, multi-point
Sample tubes/cups Primary tubes of 5, 7 and 10 mL and sample cups
Reagent on-board capacity 30 different methods in bar coded mono- or twin-containers for adapter-free one-grip loading
Reaction unit Temperature controlled heated rotor with 105 disposable plastic cuvettes (37 ± 0.2 °C)
Photometry 12 wavelengths: 340, 380, 405, 450, 480, 508, 546, 570, 600, 660, 700 and 800 nm (mono- and bichromatic)
Photometric linearity and resolution 0 – 3.0 OD; resolution: 0.0001 OD
Water consumption <1 liter per hour
LIS connectivity Given
System interface Analyzer - PC: USB connectivity bi-directional; CPU: Pentium IV or higher
Power source/power consumption AC 110/220 V, 60/50 Hz; 300 VA excluding PC/printer/monitor
Dimensions 60 cm (W) x 67 cm (D) x 60 cm (H)
Weight ±60 kg

Assay List

Proline® R-910 features wide array of programmed methods and methods identification ranging from general up to specific clinical chemistry and immunoturbidimetric testing.

For further list details, please reach our technical support team by clicking through this link.

Recommended Kit Line

Proline® R-910 is built for speed and efficient workflow. We recommend using Proline's Respons® 910/920 Kit line for automated reading flow through barcode which is compatible with the built-in tray shape.

Click here to view the kit line and list of Proline's parameters for Proline® R-910.
